Rexroth A18VO107DRS00/11NLWK0E810-0 - L variable displacement pump (ex. R902119945, KVA7V010DRS/63-MEK-64-S)
Category: variables
CODE: R902191759
CODE: R902191759
Availability: Available (quantity: 1)
Check deliveries
Product description
The A18VO is a variable displacement pump with a conical piston drive, an axial piston design with a swash plate, for open-circuit hydrostatic drives. The pump is specifically designed for demanding applications and the convenient control of work equipment in commercial vehicles, such as large truck cranes and truck superstructures. The pump's flow is proportional to the drive speed and displacement volume. Adjusting the pivot axis allows for infinitely variable flow adjustment.
Product features
- Pump type: Piston variable displacement
- Producent: Rexroth
- Adapter: bez
- Working volume: 107 cm3 / rev
- Additional functions: Bez funkcji dodatkowych, standardowe
- Turning direction: on the left
- Receiving company (external): Standard without reception
- Max. working pressure (continuous): 350 bar
- Electromagnet plugs: without plug
- Flow: 230 l/min
- Control: DRS
- Flange type: ISO 7653-1985
- Centering diameter: 80mm
- Direction of rotation: L
- Roller type: Spline 8x32x35
- Gross weight: 27.4 kg
- Load-Sensing setting: 30
- Comparison code: A18VO107DRS00/11NLWK0E810-0-77725.3116
- Max displacement volume: 107 cm³
- Max flow: 223 l/min
- Working pressure max.: 350 bar
- Max rotational speed: 2150
- Min. displacement volume: 0 cm³
- Min. flow: 0 l/min
- Mounting flange: Special flange ISO 7653-1985
- Net weight: 27.4 kg
- Paint coat/primer coat: without
- Paint coat/topcoat: without
- Connection A: DIN ISO 228 – G 1 open
- Connection and mounting thread: Metric
- M1 connection: DIN 3852 M12x1.5 closed
- MA connection: DIN 3852 M10x1 closed
- Connection plate for service lines: Threaded connections A and S on the back
- R connection: DIN 3852 M18X1.5 closed
- T-connection: DIN 3852 M12x1.5 open
- Connection X: ISO 11926 7/16-20 UNF-2B open
- Connection X2: without
- Pressure regulator setting: 350
- Product family: A18V
- Seal material: FKM (kauczuk fluorowy) 2 WDR
- Type series: 11
- Shaft end: Pinion shaft similar to DIN ISO 14
- Size: 107
- Nominal size (displacement volume): 107 cm³
- Suction port: without
- Suction connection S: DIN ISO 228 – G 1 1/4 open
- Inspection certificate: without
- Language abbreviation for inspection certificate: Without
- Type: A18V
- Startup method: Pump, open circuit
- Libra: 27.4 kg
- Steering: DRS
- Type: A18V
- Size: 107
- Direction of rotation: L
Documents
A18VO_Rexroth.pdfRelated products
