055258100200000 VSO-SE-DL-FCV-SX-38-MP
Category: Rexroth / OilControl
CODE: R930002367
CODE: R930002367
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product features
- Marking: 055258100200000 VSO-SE-FCV-DL-R-G-38NA-&
- Directly-indirectly controlled: Indirectly externally controlled
- Gross weight: 540 g
- Hydraulic fluid: HL,HLP
- Max flow rate: 30 l/min
- Net weight: 540 g
- Nominal flow rate: 30 l/min
- Max. working pressure: 210 bar
- Pre-control proportions: 5.4:1
- Number of connections: 4
- Pressure preset: Without pre-set pressure
- Pressure setting: 1.6 bar
- Product family: Single action
- Product family: Single action
- Product family classification: Indirectly controlled, single-acting check valve
- Product family type: VSO
- Product type: VSO-DL
- Seal material: NBR
- Connection type: Flange connection
- Libra: 0.54 kg
