Rexroth double check valve 3/4" 05420502043500B VBSO-DE-CC-34-1:8-35

Name: Rexroth double check valve 3/4" 05420502043500B VBSO-DE-CC-34-1:8-35
Price: 1285.71 PLN
Availability: InStock

CODE: R930001790

CODE: R930001790

Availability: Available (quantity: 3)

Check deliveries

net: 1285,71 PLN

gross: 1581,42 PLN

Ask about the product

Double check valve 3/4" Rexroth OilControl 05.42.05.02.04.35.00B VBSO-DE-CC-34-1:8-35

max. pressure: 350 bar
Marking: 05420502043500B-VBSO-DE-CC-34-35-B
Adjustable pressure range: 100-350
Directly-indirectly controlled: Indirectly externally controlled
Gross weight: 2.24 kg
Hydraulic fluid: HL,HLP
Max flow rate: 140 l/min
Net weight: 2.24 kg
pilot rate: 8.2:1
Nominal flow rate: 140 l/min
Max. working pressure: 210 bar
Connection type: G 3/4"
Pre-control proportions: 8.2:1
Number of connections: 4
Pressure preset: With pressure pre-setting
Pressure setting: 350 bar
Product family: Double acting, partially balanced valve
Producent: Rexroth
Product family: Double acting, partially balanced valve
Product family classification: Double acting, partially unloaded lowering interruption valve
Product family type: VBSO
Product type: VBSO
Seal material: NBR
Comparison code: 05420502043500B
Connection type: Threaded connection
Libra: 2.24 kg
