088116030435000 A-VAA-CC-FM-A2FE45/34-01

CODE: R930005838

CODE: R930005838

Availability: Currently not available

Notify me about availability

Price available on request +48 42 712 66 07

Ask about the product

Marking: 088116030435000 A-VAA-CC-42-FM
Adjustable pressure range: 70-350
Adjustment options: Allen screw without leaks
Directly-indirectly controlled: Indirectly controlled
Gross weight: 12.29 kg
Hydraulic fluid: HL,HLP
Max flow rate: 200 l/min
Net weight: 12.29 kg
Nominal flow rate: 200 l/min
Max. working pressure: 350 bar
Number of connections: 4
Pressure preset: With pressure pre-setting
Pressure setting: 300 bar
Product family: A-VAA-CC-42-FMA2FE-45-56-63 series
Product family classification: Impact valve, indirectly operated, with suction function, with flange surface for mounting on engines
Product family type: VAA
Seal material: NBR
Connection type: Flange connection
Libra: 12.29 kg
