05452403032000A VBSO-SE-FA-RD-30-OMP-12-1: 4-20

CODE: R930002088

CODE: R930002088

Availability: Currently not available

Notify me about availability

Price available on request +48 42 712 66 07

Ask about the product

Marking: 05452403032000A VBSO-SE30-FARD-OMR-12-2&
Adjustable pressure range: 60-210
Directly-indirectly controlled: Indirectly externally controlled
Gross weight: 1.25 kg
Hydraulic fluid: HL,HLP
Max flow rate: 60 l/min
Net weight: 1.25 kg
Nominal flow rate: 60 l/min
Max. working pressure: 210 bar
Pre-control proportions: 4.2:1
Number of connections: 6
Pressure preset: With pressure pre-setting
Pressure setting: 200 bar
Product family: Single acting, with brake air connection
Product family: Single acting, with brake air connection
Product family classification: Single acting lowering interruption valve with brake air connection for winches, with flange surface for motor
Product family type: VBSO
Product type: VBSO-30
Seal material: NBR
Connection type: Flange connection
Libra: 1.25 kg
