084632037335000 A-VBSN-DE-VF-12A-VRPF-FM-A2FE80 / 90-FC100SAE-1: 4

CODE: R930003631

CODE: R930003631

Availability: Currently not available

Notify me about availability

Price available on request +48 42 712 66 07

Ask about the product

Marking: 084632037335000 A-VBSN-20A-DE4:1VFRPFA2&
Adjustable pressure range: 140-350
Directly-indirectly controlled: Indirectly externally controlled
Gross weight: 12.91 kg
Hydraulic fluid: HL,HLP
Max flow rate: 320 l/min
Net weight: 12.91 kg
Nominal flow rate: 320 l/min
Max. working pressure: 350 bar
Pre-control proportions: 4:1
Number of connections: 8
Pressure preset: With pressure pre-setting
Pressure setting: 350 bar
Product family: Double acting, with brake air connection
Product family: Double acting, with brake air connection
Product family classification: Double acting lowering interruption valve with pressure reduction to brake air connection
Product family type: VBSN
Product type: VBSN
Seal material: NBR
Connection type: Threaded connection
Libra: 12.91 kg
