Rexroth valve 043310108503000-VSOA-10A-03-OR
Category: Rexroth / OilControl
CODE: R901117421
CODE: R901117421
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Rexroth valve 043310108503000-VSOA-10A Max. pressure: 350 bar Max. flow: 40 l / min Pilot Ratio: 3: 1 Cavity / Ports: Size 10 Hex 27 7 / 8-14 UNF-2A
Product features
- Valve seat: CA-10A-3N
- Directly-indirectly controlled: Indirectly externally controlled
- Gross weight: 104 g
- Hydraulic fluid: HL,HLP
- Max flow rate: 40 l/min
- Net weight: 104 g
- Nominal flow rate: 40 l/min
- Max. working pressure: 350 bar
- Pre-control proportions: 3:1
- Number of connections: 3
- Pressure preset: Without pre-pressure setting
- Pressure setting: 3.5 bar
- Product family: Releasable check valve
- Product family: Releasable check valve
- Product family classification: Check valves, with the possibility of unblocking
- Product family type: VSOA
- Product type: VSOA
- Seal material: NBR
- Valve cone slide: Socket version
- Connection type: Screw-in valve
- Libra: 0.11 kg
043310X85Z.pdf
