Parker engine F11-010-QB-CV-X-259-0000-00
Category: Piston engines
CODE: 3702695
CODE: 3702695
Availability: Available (quantity: 1) , shipping within 30 dni
Check deliveries
Product description
Parker F11-010-QB-CV-X-259-0000-00 engine Special version - conical shaft Suction connection: G3/4" BSP Discharge connection: G3/4" BSP Leakage connection: G3/8" BSP
Product features
- Producent: Parker
- Engine Series: F11
- Working volume: 9.8 cm3/rev
- Turning direction: Bi-directional
- Max. working pressure (continuous): 350 bar
- Maximum flow (continuous): 100 l/min
- Flange type: Cetop
- Spacing of mounting holes: 125 mm
- Centering diameter: 100mm
- Roller type: Conical (special)
- Shaft seal: FPM
- Main ports: Gwinty BSP
- Compressing port: G 3/4"
- Suction port: G 3/4"
- Colour: Unpainted
- Additional function: Low noise level
