Piston pump Hydro Leduc W12, Right rotation

CODE: 0521380

Availability: Currently not available

Check deliveries

Category: Single-stream

Product features:

Working volume: 12 cm3 / rev

Turning direction: Right

Max. working pressure (continuous): 400 bar

Centering diameter: 80 mm

Roller type: Cylindrical ø25 mm

Pump type: Single-stream piston

Producer: Hydro Leduc

Description: Hydro Leduc W series piston pump W series (ISO version) WA series (SAE version) Available with a cylindrical shaft with a keyway or a splined shaft Flange type: square - 4 holes ø9 mm Shaft journal: cylindrical ø25 mm, keyway DIN 6885 AS 8x7x32 Connection Suction: M27x2 Discharge connection: M22x1.5 Leakage connection: M12x1.5 Detailed data with dimensions can be found in the pdf appendix

Comparison code: AD1RM2SHHP

PDF files

hydroleduc_w_en.pdf

hydroleduc_w_pump_en.pdf

hydroleduc_wa-series-pump-EN.pdf
