Vane pump Rexroth PV7-1X / 100-118RE07MC0-16
Category: Vane pumps
CODE: R900506809
CODE: R900506809
Availability: Available (quantity: 1) , shipping within 30 dni
Check deliveries
Product description
High reliability in industrial applications. Low noise and pulsation levels. Precise control behavior thanks to low hysteresis with high repetition accuracy. Can be flexibly combined with other Rexroth pumps.
Product features
- Producent: Rexroth
- Seria pompy: PV7
- Direction of rotation: right turns
- Pump type: Shoulder blade
- Displacement type: variable
- ECLASS_13_Classification: 51-41-05-02
- Gross weight: 57.76 kg
- Hydraulic fluid: HLP,HLPD,HVLP,HVLPD
- Max flow rate: 171 l/min
- Mounting: 4-hole mounting flange 160B4HW according to ISO 3019-2
- Net weight: 57.76 kg
- Max. working pressure: 160 bar
- Product family: PV7...C/D/N/W
- Seals: NBR
- End of the shaft: Cylindrical Ø 40 mm with keyway, ISO 3019-2
- Nominal size: 118 cm³
- Through drive: With
- Libra: 57.76 kg
R900506809
