Hydraulic gear pump SHIMADZU SDY1A36-16L168
Category: O.K. White
CODE: WH 5S2/49001TCM
CODE: WH 5S2/49001TCM
Availability: Available (quantity: 5) , shipping within 7 dni
Check deliveries
Product features
- Working volume: 36,6+15,9 cm3/obr
- Turning direction: Left
- Centering diameter: 82,5 mm
- Roller type: Spline - 13 teeth
- Flange type: 106mm, 2 bolts
- Pump type: Double toothed
- Comparison code: 403-40168, SDY1A36-16L168
