Parker TG0140EW441BBBF hydraulic motor
Category: TG series
CODE: WH WTG0140EW441BBBF
CODE: WH WTG0140EW441BBBF
Availability: Available (quantity: 1) , shipping within 7 dni
Check deliveries
Product description
Parker Torqmotor™ TG Series hydraulic motors offer increased power and durability , designed for demanding industrial and mobile applications. Thanks to their robust design and high-quality materials, TG Series motors ensure stable operation, high efficiency, and long service life in harsh operating conditions.
The TG series is distinguished by:
Various types of mounting flanges – flanged and circular, enabling easy adaptation to mechanical systems and machines.
Output shafts adapted to standard clutches and gearboxes, making integration into hydraulic systems easier.
Different continuous and intermittent pressures , ensuring safe operation under standard and momentary loads.
TG engines are used in:
industrial and mobile machines
power hydraulic systems
agricultural machinery and commercial vehicles
systems requiring high torque in a compact design
Note: Please verify the engine dimensions corresponding to the given working volume.
Product features
- Producent: Parker
- Engine Series: TG
- Engine type: Torqmotor
- Working volume: 141 cm3/obr
- Max. working pressure (continuous): 210 bar
- Maximum flow (continuous): 75 l/min
- Flange type: SAE "A", 6 bolt
- Spacing of mounting holes: 106,4 mm
- Centering diameter: 82,5 mm
- Roller type: Spline - 14 teeth, (12/24 P.)
- Main ports: BSP threads
- Compressing port: G 1/2"
- Suction port: G 1/2"
- Colour: Unpainted
- Additional option: 200 bar safety valve
- Comparison code: TG0140EW441BBBF, 55093400
