Parker TG0240HW080AAAA Hydraulic Motor
Category: TG series
CODE: WH WTG0240HW080AAAA
CODE: WH WTG0240HW080AAAA
Availability: Available (quantity: 1) , shipping within 7 dni
Check deliveries
Product description
Parker Torqmotor™ TG Series hydraulic motors offer increased power and durability , designed for demanding industrial and mobile applications. Thanks to their robust design and high-quality materials, TG Series motors ensure stable operation, high efficiency, and long service life in harsh operating conditions.
The TG series is distinguished by:
Various types of mounting flanges – flanged and circular, enabling easy adaptation to mechanical systems and machines.
Output shafts adapted to standard clutches and gearboxes, making integration into hydraulic systems easier.
Different continuous and intermittent pressures , ensuring safe operation under standard and momentary loads.
TG engines are used in:
industrial and mobile machines
power hydraulic systems
agricultural machinery and commercial vehicles
systems requiring high torque in a compact design
Note: Please verify the engine dimensions corresponding to the given working volume.
Product features
- Producent: Parker
- Engine Series: TG
- Engine type: Torqmotor
- Working volume: 238 cm3/obr
- Max. working pressure (continuous): 210 bar
- Maximum flow (continuous): 75 l/min
- Flange type: Wheel - 4 holes
- Centering diameter: 82,5 mm
- Roller type: Conical 1:8
- Main ports: BSP threads
- Compressing port: G 1/2"
- Suction port: G 1/2"
- Colour: Black
- Comparison code: TG0240HW080AAAA
Documents
Dane techniczne Parker TG 2011Related products
Parker TG0240HW080AAAA Hydraulic Motor
Availability: Available
(quantity: 1)
, 30 dni
net: 3528,30 PLN
