PROPORTIONAL PRESSURE VALVE DBEP6C06-1X/45AG24K4M
Category: Rexroth / OilControl
CODE: R900955082
CODE: R900955082
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Industrial hydraulic valve for high power range. Reliable pressure limitation based on a setpoint signal.
Product features
- Connection diagram: ISO 4401-03-02-0-05
- ECLASS_13_Classification: 51-45-02-01
- Electric connection description: 3-pole device plug (2 + PE) according to EN 175301-803
- Plug: 3-pole device plug (2 + PE)
- Gross weight: 2.66 kg
- Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HFC
- Max flow rate: 8 l/min
- Net weight: 2.66 kg
- Max. working pressure: 100 bar
- Seals: NBR
- Nominal size: 6
- Slider graphic symbol: P → A, P → B / A → T, B → T
- Supply voltage: 24 VDC
- Connection type: Mounting on a board
- Number of connections: 4
- Valve position number: 2
- Libra: 2.66 kg
Proportional pressure relief valve
