HYDRAULICZNY ZAWÓR UPUSTOWY DB20-2-4X/350XW65
Category: Rexroth / OilControl
CODE: R900508267
CODE: R900508267
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Industrial hydraulic valve for high power range. Reliable pressure limitation to set value.
Product features
- Connection diagram: ISO 6264-08-13
- ECLASS_13_Classification: 51-44-02-01
- Gross weight: 2.6 kg
- Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HFC (Fuchs: Hydrotherm 46M, Renosafe 500, Petrofer: Ultra Safe 620, Houghton: Safe 620, Union: Carbide HP5046)
- Max flow rate: 400 l/min
- Net weight: 2.6 kg
- Max. working pressure: 350 bar
- Product family: DB.10,20
- Seals: NBR
- Nominal size: 25
- Connection type: Mounting on a board
- Number of connections: 2
- Valve position number: 2
- Libra: 2.6 kg
Pressure relief valve, pilot-operated
