Rexroth A2FM90/61W-VBB027 axial piston motor
Category: Rexroth
CODE: R992001975
CODE: R992001975
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
The A2FM is a constant displacement motor with a conical piston drive, an axial piston design with a swashplate, designed for open-loop and closed-loop hydrostatic drives. In axial piston units with a swashplate, the pistons are arranged diagonally relative to the drive shaft. The pistons rest directly on the drive shaft and, depending on the pressure, generate torque on it.
Product features
- Working volume: 90 cm3/obr
- Marking: A2FM90/61W-VBB027
- Direction of rotation: IN
- Max. working pressure (continuous): 350 bar
- Gross weight: 28.8 kg
- Flow: 4050 l/min
- Net weight: 28.8 kg
- Centering diameter: 140 mm
- Operation: M
- Flange type: ISO 3019-2, 4 bolts
- Product family: A2FM
- Roller type: Spline DIN 6885 AS12x8-56
- Series: 6
- Producent: Rexroth
- Size: 90
- Type: A2F
- Comparison code: R902138035
- Libra: 28.8 kg
- Action: M
- Number: 6
- Direction of rotation: W
- Type: A2F
- Size: 90
