Wał przegubowo-teleskopowy 1450-2200mm 1950Nm szerokokątny Z21 dr. st. sprzęgło cierne 2500Nm Z21 CE 2020 seria 9X Waryński
Category: Seria 9R 1890Nm
CODE: WX992621450
CODE: WX992621450
Availability: Available (quantity: 1)
Check deliveries
Product description
Shaft made according to the new PN-EN-12965_2020 Standard. Waryński R Series Shafts were created to better meet the needs of our customers. The changed design has increased the service life and durability of our products by over 15%. Thanks to the use of a specialized locking system, Waryński shafts guarantee quick assembly and safety and are compliant with the new Standard. The high quality of our products is guaranteed by forks made of high-carbon steel, crosspieces equipped with special bearings of increased strength and Waryński articulated-telescopic shaft housings resistant to mechanical impacts, UV and low temperatures.
Product features
- Producent: WARYNSKI
- Tractor mount: 1 3/8" - Z21 inch
- Attachment to the machine: 1 3/8" - Z21 inch
- Telescopic connector type: Star pipe
- Maximum length: 2200mm
- Nominal power: 113 ( 151 ) KW ( HP )
- Inner tube thickness: 61mm
- Outer pipe thickness: 71.5mm
- Bearing diameter: 41mm
- Height of the cross: 118mm
- Collaborates with: Outer pipe yoke - WR227901, Crosspiece - WR219901, Outer pipe yoke - , Inner pipe yoke - , Inner pipe - , Outer pipe - , Housing - WR21991129
- Torque: 1950 Nm
- Working angle: Max 35° temporarily 80°
- Inner pipe wall thickness: 4.5mm
- Outer pipe wall thickness: 5mm
- Clutch release torque: 2500 Nm
- Clutch from the Machine side: Friction clutch
- Clutch from Tractor side: Wide angle
