Wał przegubowo-teleskopowy 1010-1560mm 970Nm sprzęgło cierne 1700Nm CE 2020 seria 7R Waryński
Category: Seria 7R 970Nm
CODE: W7B1601010
CODE: W7B1601010
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Shaft made according to the new PN-EN-12965_2020 Standard. Waryński R Series Shafts were created to better meet the needs of our customers. The changed design has increased the service life and durability of our products by over 15%. Thanks to the use of a specialized locking system, Waryński shafts guarantee quick assembly and safety and are compliant with the new Standard. The high quality of our products is guaranteed by forks made of high-carbon steel, crosspieces equipped with special bearings of increased strength and Waryński articulated-telescopic shaft housings resistant to mechanical impacts, UV and low temperatures.
Product features
- Producent: WARYNSKI
- Tractor mount: 1 3/8" - Z6 inch
- Attachment to the machine: 1 3/8" - Z6 inch
- Telescopic connector type: Triangular pipe
- Maximum length: 1560mm
- Nominal power: 55 ( 75 ) KW ( HP )
- Clutch: friction clutch
- Inner tube thickness: 45mm
- Outer pipe thickness: 54mm
- Bearing diameter: 30.2mm
- Height of the cross: 106mm
- Collaborates with: Outer yoke -WR227701, WR213750, Crosspiece - WR219701, Inner pipe yoke - WR219707, Outer pipe yoke - WR219706, Inner pipe - WR2140600, WR2362885, Outer pipe - WR2141600, WR2363855, Housing - WR21971129,
- Clutch release power: 1700
- Torque: 970 Nm
- Working angle: Max 17°
- Inner pipe wall thickness: 5.5mm
- Outer pipe wall thickness: 4mm
- Clutch release torque: 1700 Nm
- Clutch from the Machine side: Friction clutch
- Clutch from Tractor side: Lack
