Wał przegubowo-teleskopowy 510-720mm 460Nm widłak Z21 skręcany na śrubę 50210 CE seria 3R WARYŃSKI
Category: Seria 3R 460Nm
CODE: W32112510
CODE: W32112510
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product features
- Producent: WARYNSKI
- Tractor mount: 1 3/8" - Z6 inch
- Attachment to the machine: 1 3/8" - Z21 inch
- Telescopic connector type: Triangular pipe
- Maximum length: 720mm
- Nominal power: 26 ( 35 ) KW ( HP )
- Inner tube thickness: 36mm
- Outer pipe thickness: 43.5mm
- Bearing diameter: 27mm
- Height of the cross: 74.6mm
- Collaborates with: Outer tube yoke - WR227301, Crosspiece - WR219301, Outer tube yoke - WR219306, Inner tube yoke - WR219307, Inner tube - WR2323355, Outer tube - WR2322385, Housing - WR22931129
- Torque: 460 Nm
- Working angle: Max 17°
- Inner pipe wall thickness: 4.5mm
- Outer pipe wall thickness: 3.4mm
- Clutch release torque: No Nm
- Clutch from the Machine side: Lack
- Clutch from Tractor side: Lack
