Wał przegubowo-teleskopowy 1010-1560mm 460Nm sprzęgło z kołkiem szerokokątny CE seria 3R WARYŃSKI
Category: Seria 3R 460Nm
CODE: W371901010
CODE: W371901010
Availability: Available (quantity: 7)
Check deliveries
Product description
The new R Series of Waryński shafts was created to better meet the needs of our customers. The changed design has allowed us to increase the service life and durability of our products by over 15%. The high quality of our products is guaranteed by forged forks made of high-carbon steel, crosspieces equipped with special bearings of increased durability and housings of Waryński articulated-telescopic shafts resistant to mechanical impacts, UV effects and low temperatures. Thanks to the use of a special ring, Waryński shafts guarantee quick assembly.
Product features
- Producent: WARYNSKI
- Tractor mount: 1 3/8" - Z6 inch
- Attachment to the machine: 1 3/8" - Z6 inch
- Telescopic connector type: Rura trójkątna
- Maximum length: 1560mm
- Nominal power: 26 ( 35 ) KW ( HP )
- Clutch: sprzęgło z kołkiem, szerokokątny
- Inner tube thickness: 36mm
- Outer pipe thickness: 43.5mm
- Bearing diameter: 27mm
- Height of the cross: 74.6mm
- Collaborates with: Widłak zewnętrzny - WR227301, Krzyżak - WR219301, Widłak rury wew. - WR219307, Widłak rury zew. - WR219306, Rura wewnętrzna - WR2323855, Rura zewnętrzna - WR2322885, Obudowa - WR21931129
- Torque: 460 Nm
- Working angle: Max 35° chwilowo 80°
- Inner pipe wall thickness: 4.5mm
- Outer pipe wall thickness: 3.4mm
- Clutch release torque: 1400 Nm
- Clutch from the Machine side: Szerokokątny
- Clutch from Tractor side: Sprzęgło z kołkiem
