Wał przegubowo-teleskopowy 510-720mm 460Nm szerokokątny od st.maszyny CE 2020 seria 3R WARYŃSKI
Category: Seria 3R 460Nm
CODE: W3B190510
CODE: W3B190510
Availability: Available (quantity: 3)
Check deliveries
Product description
The shaft is manufactured according to the new PN-EN-12965_2020 standard. The Waryński R Series shafts were created to better meet the needs of our customers. The revised design has increased the service life and durability of our products by over 15%. Thanks to the use of a specialized locking system, Waryński shafts guarantee quick assembly and safety, and are compliant with the new standard. The high quality of our products is guaranteed by forks made of high-carbon steel, crosspieces equipped with special, increased-strength bearings, and Waryński PTO shaft housings resistant to mechanical impact, UV exposure, and low temperatures.
Product features
- Producent: WARYNSKI
- Tractor mount: 1 3/8\" - Z6 cal
- Attachment to the machine: 1 3/8\" - Z6 cal
- Telescopic connector type: Rura trójkątna
- Maximum length: 720mm
- Nominal power: 26 ( 35 ) KW ( HP )
- Clutch: Szerokokątne
- Inner tube thickness: 36mm
- Outer pipe thickness: 43.5mm
- Bearing diameter: 27mm
- Height of the cross: 74.6mm
- Collaborates with: Widłak zewnętrzny - WR227301, Krzyżak - WR219301, Widłak rury wew. - WR219307, Przegub szerokokątny - WR212290, Rura wewnętrzna - WR2323355, Rura zewnętrzna - WR2322385, Obudowa - WR22931129
- Clutch release power: Brak
- Torque: 460 Nm
- Working angle: Max 35° chwilowo 80°
- Inner pipe wall thickness: 4.5mm
- Outer pipe wall thickness: 3.4mm
- Clutch release torque: No Nm
- Inner tube thickness:: 36mm
- Outer pipe thickness:: 43.5mm
- Clutch from the Machine side: Szerokokątny
- Clutch from Tractor side: Brak
