Monoblock distributor 45l/min G3/8"; 1-section 24V
Category: Youli
CODE: HPMV-3/1S-3/18 ES3/G-3/M1-24V
CODE: HPMV-3/1S-3/18 ES3/G-3/M1-24V
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Monoblock distributor 45l/min G3/8", 1-section, electrically controlled 24V
Directly controlled overflow valve, range 63-200 bar (setting 120 bar)
Slider type: 4/3, in neutral position P,A,B,T - closed, By-Pass C - open to T (code: HPMB33001)
Product features
- max. pressure: 350 bar
- Flow: 45 l/min
- Number of sections: 1
- Manifold type: HPMV-3
- Producent: Mobitec & Youli
Dokumentacja techniczna
