Rexroth Hydraulic Valve 041149035620000 VSBN-08A-20 105-210 BAR
Category: Rexroth / OilControl
CODE: R901097728
CODE: R901097728
Availability: Available (quantity: 1)
Check deliveries
Product description
Directly operated pressure relief valves, socket version
Product features
- max. pressure: 350 bar
- Adjustable pressure range: 105-210
- Adjustment options: Allen screw without leaks
- Flow: 20 l/min
- Valve seat: CA-08A-2N
- Setting range: 105-210 bar
- Directly-indirectly controlled: Directly controlled
- Gross weight: 91 g
- Hydraulic fluid: HL,HLP
- Max flow rate: 20 l/min
- Net weight: 91 g
- Recess: CA-08A-2N
- Nominal flow rate: 20 l/min
- Normal position: Currentless closed
- Max. working pressure: 350 bar
- Number of connections: 2
- Pressure preset: With pressure pre-setting
- Producent: Rexroth
- Pressure setting: 200 bar
- Product family: Relief
- Product family: Relief
- Product family classification: Directly operated pressure relief valves, socket version
- Product family type: VSBN
- Comparison code: 041149035620000
- Product type: VSBN
- Seal material: NBR
- Valve cone slide: Socket version
- Connection type: Screw-in valve
- Libra: 0.1 kg
