BMSS 250 orbital engine
Category: Orbitrols
CODE: BMSS-250
CODE: BMSS-250
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
BMSS Hydraulic Motor - Danfoss OMSS Replacement
The BMSS series orbital motors are durable and efficient hydraulic units designed for harsh environments. They are a fully functional replacement for Danfoss OMSS motors , maintaining installation compatibility and operating parameters.
Main features:
Bidirectional rotation (left/right)
High torque at low speed
Solid construction and durable seals
Resistance to heavy loads
Applications: agricultural, forestry, municipal, construction and industrial machines, wherever a reliable high-pressure orbital engine is needed.
Please verify the engine dimensions corresponding to the given working volume.
Product features
- Producent: Rolltorq
- Engine Series: BMSS
- Engine type: Orbitalne
- Working volume: 252,6 cm3/obr
- Turning direction: Two-way
- Max. working pressure (continuous): 230 bar
- Maximum flow (continuous): 75 l/min
- Flange type: Wheel - 4 holes
- Spacing of mounting holes: 125 mm
- Centering diameter: 100 mm
- Roller type: Spline - 12 teeth, (12/24), 12DP
- Power (kW): 18
- Main ports: BSP threads
- Compressing port: G 1/2"
- Suction port: G 1/2"
- Drainage port: G 1/4"
- Comparison code: TMSS.250, TMSS-250, TMSS250, OMSS-250, OMSS250, OMS250, OMS-250
