Hydraulic quick coupler socket long M22x1.5 external thread EURO (9100822GL) (ISO 7241-A) Waryński (pack of 50 pieces)
Category: Quick couplers
CODE: WIAM22MZL-50
CODE: WIAM22MZL-50
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Waryński hydraulic quick coupler - long socket with EURO locknut. The most popular hydraulic quick coupler with a very wide range of applications. Designed in accordance with the dimensional and quality requirements of the ISO 7241 Series A standard, which specifies detailed characteristics and dimensions to enable compatibility between quick couplers manufactured by different manufacturers in accordance with this standard. Interchangeable with ISO-A quick couplers from other manufacturers, such as Parker, Faster, Stucchi, DNP, Tema, and others.
Product features
- Producent: WARYNSKI
- Working temperature: od -25 do +120 °C
- Fits plugs: WIAM14SZ, WIAM16SZ, WIAM16SZL, WIAM18SZ, WIAM18SZL, WIAM22SZ, WIAM22SZL, WIAM20SZ, WIAR12SW, 9100820W, 9100816W, 9100818W, 9100822W, 9100814W, 9100820W; WIAM18SWE; WIAM18SZE; WIAM18SZLE; WIAM20SZE; WIAM22SWE; WIAM22SZE; WIAM22SZLE; WIAR12WE
- Fits the cover: RM-GNIA12Z, 5049004EURO
- External thread: Zewnętrzny długi z przeciwnakrętką M22x1,5
