DBEME10-7X/200YG24K31A1M
Category: Rexroth / OilControl
CODE: R901353062
CODE: R901353062
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Industrial hydraulic valve for high power range. Reliable pressure limitation based on a setpoint signal.
Product features
- Conformity: UKCA,CE
- Compliance Description: UKCA – Electromagnetic Compatibility (EMC) SI2016/1091,CE – Electromagnetic Compatibility (EMC) Directive 2014/30/EU
- Connection diagram: ISO 6264
- Communication: Analog, setpoint 0…10 V
- ECLASS_13_Classification: 51-45-02-01
- Electric connection description: 7-pin device plug (6 + PE) according to EN 175201-804
- Plug: 7-pin device plug (6 + PE)
- Gross weight: 4.66 kg
- Hydraulic fluid: HL,HLP,HETG,HFC
- Max flow rate: 700 l/min
- Net weight: 4.66 kg
- Max. working pressure: 350 bar
- Product family: DBEM(E)
- Producent: BOSCH REXROTH
- Seals: NBR
- Nominal size: 10
- Slider graphic symbol: P → T, P → Y
- Supply voltage: 24 VDC
- Comparison code: R900954708
- Connection type: Mounting on a board
- Number of connections: 4
- Valve position number: 2
- Libra: 4.66 kg
