Scanreco Pocket G5 8-button 2.4 GHz transmitter

G5 Transmitters Pocket - portable control transmitter

The G5 Transmitters Pocket is a compact and reliable radio transmitter designed for convenient and safe operation of machinery and equipment. Its robust construction, resistance to harsh environmental conditions, and intuitive operation make it ideal for industrial and mobile applications.

Key features

• Lightweight yet durable housing - water and impact resistant
• From 3 to 8 buttons for flexible control configuration
• 5 LEDs provide clear information about the status of the machine and transmitter
• Battery powered (3 × AAA) - long operating time without the need for frequent battery replacement
• Belt clip - convenient and secure attachment to the operator's clothing

Technical data

• Platform: G5
• Power supply: 3 × AAA batteries
• Protection class: IP67
• LEDs: 5 (from left: green, yellow, yellow, yellow, red)
• Radio frequency: 2.4 GHz with frequency hopping technology
• Working range: > 100 m (approx. 330 ft)
• Current consumption: 10–60 mA (depending on the number of active LEDs)
• Operating time: several months (depending on the intensity of use and application)
• Certifications: TR05, integrated ISM-band duplex radio, R&TTE, FCC and IC compliant
• Operating temperature: from -25°C to +70°C
• Dimensions (W x H x D): 67 x 115 x 38 mm
• Weight: 160 g (with batteries)
