M+S 100 cm3/rev gerotor hydraulic motor
Category: M+S
CODE: MSS100
CODE: MSS100
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product features
- Producent: M+S Hydraulic
- Engine Series: MSS
- Engine type: Orbitalne
- Working volume: 100 cm3/obr
- Turning direction: Two-way
- Maximum flow (continuous): 75 l/min
- Flange type: Wheel - 4 holes
- Spacing of mounting holes: Ø125 mm
- Centering diameter: 100 mm
- Roller type: Spline 12 DP 12/24 ANS B92. 1-76
- Main ports: BSP threads
- Compressing port: G 1/2"
- Suction port: G 1/2"
