Hydraulic quick coupler long socket with pressure eliminator M22x1.5 external thread EURO (504900) (9199822G/ST) (ISO 7241-A) Waryński (pack of 10)
Category: EURO quick couplers
CODE: WIAM22MZL-STE-10
CODE: WIAM22MZL-STE-10
Availability: Available (quantity: 3)
Check deliveries
Product description
Waryński hydraulic quick coupler (Adaptation of the old type 504900) - socket with EURO long pressure eliminator (long thread with locknut. External thread on the quick coupler body with nuts adapted for installation in old type tractors. Quick couplers are designed in accordance with the dimensional and quality requirements of the ISO 7241 Series A standard, which specifies in detail the characteristics and dimensions to enable compatibility of quick couplers produced by different manufacturers in accordance with this standard.
Product features
- Producent: WARYNSKI
- Working temperature: od -25 do +120 °C
- Fits plugs: WIAM14SZ, WIAM16SZ, WIAM16SZL, WIAM18SZ, WIAM18SZL, WIAM22SZ, WIAM22SZL, WIAM20SZ, WIAR12SW, 9100820W, 9100816W, 9100818W, 9100822W, 9100814W, 9100820W; WIAM18SWE; WIAM18SZE; WIAM18SZLE; WIAM20SZE; WIAM22SWE; WIAM22SZE; WIAM22SZLE; WIAR12WE; WIAM14SZE; WIAM16SZE; WIAM16SZLE; WIAR12SZE; WIAR12SZ
- Fits the cover: RM-GNIA12Z, 5049004EURO
- External thread: Zewnętrzny M22x1,5 (długi z przeciwnakrętką)
