Bosch Rexroth AZPF-11-011LCB20MB gear pump
Category: Rexroth
CODE: 0510525311
CODE: 0510525311
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Turning direction: Direction of rotation left
- Seria pompy: AZPF
- Pump type: toothed
- Drive shaft: Conical 1:5
- Front cover: Rectangular flange Ø80 mm
- Action: Pompa
- Gross weight: 3504 g
- Enclosure material: Aluminium
- Impulse pressure max.: 280 bar
- Maximum RPM: 3500 rpm
- Construction variant: High perf (F) (4..28 cm³/U)
- Net weight: 3504 g
- Noise level: Standardowy poziom hałasu
- Nominal size: 11 cm³/rev
- Cable connection: Square collar (ni version)
- Product: External gear assembly
- End cover: Standard (gray cast iron)
- Seal material: NBR
- Number: Bearing diameter 18 mm
- Version: Fosfor., dopas. pokrywy
- Libra: 3.51 kg
- Comparison code: SNP2 A11L C002, A11LKBBB, 2017008
Documents
