AZPF-11-011RRR20KB-S0081
Category: Rexroth
CODE: 0510525072
CODE: 0510525072
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Turning direction: Direction of rotation to the right
- Seria pompy: AZPF
- Pump type: toothed
- Drive shaft: SAE J744 16-4 9T Pinion Shaft
- Front cover: 2-hole SAE J744 82-2 (A)
- Action: Pompa
- Gross weight: 3.2 kg
- Enclosure material: Aluminium
- Impulse pressure max.: 280 bar
- Maximum RPM: 3500 rpm
- Construction variant: High perf (F) (4..28 cm³/U)
- Net weight: 3.2 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 11 cm³/rev
- Custom version: Deviations from the standard catalog version, see drawing
- Cable connection: Square collar (ni version)
- Product: External gear assembly
- End cover: Standard (gray cast iron)
- Seal material: NBR, WDR w FKM
- Number: Bearing diameter 18 mm
- Version: Fosfor., dopas. pokrywy
- Libra: 3.2 kg
- Comparison code: 0510525019
RA51217862_0510325023_20210819.pdf
