Bosch Rexroth gear pump AZPF-11-014LCP20PB-S0007
Category: Rexroth
CODE: 0510515320
CODE: 0510515320
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Turning direction: Direction of rotation left
- Seria pompy: AZPF
- Pump type: toothed
- Drive shaft: Conical 1:5
- Front cover: 2-point Ø50 mm (option 2)
- Action: Pompa
- Gross weight: 2975 g
- Enclosure material: Aluminium
- Impulse pressure max.: 210 bar
- Maximum RPM: 3000 rpm
- Construction variant: High perf (F) (4..28 cm³/U)
- Net weight: 2975 g
- Noise level: Standardowy poziom hałasu
- Nominal size: 14 cm³/rev
- Custom version: Para desvios em relação aos padrões de catálogo, ver desenho
- Cable connection: Square collar (ni version)
- Product: External gear assembly
- End cover: Standard (gray cast iron)
- Seal material: FKM
- Number: Bearing diameter 18 mm
- Version: Fosfor., dopas. pokrywy
- Libra: 2.98 kg
- Comparison code: WH 5B1/40022FAH, 0510/515/320
