Rexroth 4WE 6 D6X/EX230N9K4 spool valve
Category: Rexroth
CODE: R900909559
CODE: R900909559
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Rexroth slide distributor 4WE 6 D62/EW230N9K4 DIN coil 230 VAC R900071030
Product features
- Type: 4-WE-6
- Compliance Description: UKCA – Low-Voltage Directive SI2016/1091,CE – Low-Voltage Directive 2014/35/EU
- max. pressure: 350 bars
- Conformity: UKCA,CE
- Flow: 60 l/min
- Connection diagram: ISO 4401-03-02-0-05
- Producent: Rexroth
- ECLASS_13_Classification: 51-44-01-02
- Electric connection description: Connector, 3-pole (2 + PE) according to EN 175301-803
- Comparison code: 4WE 6 D62/EW230N9K4
- Plug: Connector, 3-pole (2 + PE)
- Gross weight: 1.32 kg
- Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HFC
- Max flow rate: 60 l/min
- Net weight: 1.32 kg
- Max. working pressure: 350 bar
- Product family: WE6../E
- Seals: NBR
- Nominal size: 6
- Slider graphic symbol: Symbol D
- Supply voltage: 230 VAC 50/60Hz
- Connection type: Subplate mounting
- Number of connections: 4
- Valve position number: 2
- Libra: 1.32 kg
