AZPF-22-019LCR20PB-S0177
Category: Rexroth
CODE: 0510625399
CODE: 0510625399
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Turning direction: Left turns
- Pump type: toothed
- Drive shaft: Conical 1:5
- Front cover: SAE J744 82-2 (A)
- Action: Pompa
- Gross weight: 4.3 kg
- Enclosure material: Aluminium
- Impulse pressure max.: 250 bar
- Maximum RPM: 3600 rpm
- Construction variant: Design variant F (4 ... 28 cm³/rev)
- Net weight: 4.3 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 19 cm³/rev
- Custom version: Para desvios em relação aos padrões de catálogo, ver desenho
- Cable connection: Square flange DIN 3901/3902
- Product: External gear assembly
- End cover: Standard
- Seal material: FKM
- Number: Bearing diameter Ø 20mm
- Version: zabezpieczenie przed korozją, z kołkami
- Libra: 4.3 kg
