Rexroth 4WE 6 J6X/EG24N9K4 directional slide distributor
Category: Rexroth
CODE: R900561288
CODE: R900561288
Availability: Available (quantity: 1) , shipping within 10 dni
Check deliveries
Product description
Equivalent to the new series of R900456448 4WE 6 J5X / AG24NZ4 manifold
Product features
- Connection diagram: ISO 4401-03-02-0-05
- ECLASS_13_Classification: 51-44-01-02
- Electric connection description: Connector, 3-pole (2 + PE) according to EN 175301-803
- Plug: Connector, 3-pole (2 + PE)
- Gross weight: 1.99 kg
- Hydraulic fluid: HL,HLP,HLPD,HVLP,HVLPD,HFC
- Max flow rate: 80 l/min
- Net weight: 1.99 kg
- Max. working pressure: 350 bar
- Product family: WE6../E
- Seals: NBR
- Nominal size: 6
- Slider graphic symbol: Symbol J
- Supply voltage: 24 VDC
- Connection type: Subplate mounting
- Number of connections: 4
- Valve position number: 3
- Libra: 1.99 kg
Rozdzielacze suwakowe sterowane bezpośrednio elektromagnesem
