OD113139A000000

Category: Rexroth

CODE: R930058705

CODE: R930058705

Availability: Currently not available

Notify me about availability

Price available on request +48 42 712 66 07

Ask about the product

Marking: OD113139A000000-VED-016-NC-08F-A-31-0000
Valve seat: 20-01-03
Coil: D36
Integrated coil: Separate order
Directly-indirectly controlled: Directly controlled
Gross weight: 130 g
Hydraulic fluid: HL,HLP
Max flow rate: 15 l/min
Net weight: 130 g
Nominal flow rate: 15 l/min
Normal position: Currentless closed
Max. working pressure: 250 bar
Number of connections: 2
Positions: 2
Product family: 2-way
Product family: 2-way
Product family classification: Magnetically actuated, direct-acting seat-mounted valves, 2-way, double-locking
Product family type: VEDT
Product type: VEDT
Seal material: NBR
Valve cone slide: Socket version
Connection type: Screw-in valve
Libra: 0.13 kg
