AZPF-11-011RCB20MB
Category: Rexroth
CODE: 0510525009
CODE: 0510525009
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Seria pompy: AZPF
- Pump type: toothed
- Drive shaft: Conical 1:5
- Working volume: 11 cm3 / rev
- Front cover: Rectangular flange Ø80 mm
- Turning direction: Direction of rotation to the right
- Action: Pompa
- Max. working pressure (continuous): 250 bar
- Gross weight: 3.55 kg
- Enclosure material: Aluminium
- Impulse pressure max.: 280 bar
- Maximum RPM: 4000 rpm
- Construction variant: High perf (F) (4..28 cm³/U)
- Net weight: 3.55 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 11 cm³/rev
- Cable connection: Square collar (ni version)
- Product: External gear assembly
- End cover: Standard (gray cast iron)
- Seal material: NBR
- Number: Bearing diameter 18 mm
- Version: Fosfor., dopas. pokrywy
- Libra: 3.55 kg
- Comparison code: 432222, SNP2/11D CO02, 0510 525 009
