Bosch Rexroth gear pump (EX. 1517222874 - AZPB-10-2,0LNEXXMA-S0073)
Category: Rexroth
CODE: 0510110337
CODE: 0510110337
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Seria pompy: AZPB
- Drive shaft: Double-walled tusk
- Front cover: Connecting flange (CPMBosch EP9)
- Turning direction: Direction of rotation left
- Action: Pompa
- Gross weight: 1.2 kg
- Enclosure material: Aluminium
- Impulse pressure max.: 250 bar
- Maximum RPM: 5000 rpm
- Construction variant: High perf (B)(1.0..7.1 cm³/U)
- Net weight: 1.2 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 2 cm³/rev
- Cable connection: Special execution
- Product: External gear assembly
- End cover: Axial pressure and suction connections
- Seal material: NBR
- Number: Bearing diameter 12 mm or 12.7 mm
- Version: Ocynk. lub al., dopas. pokrywy
- Libra: 1.2 kg
- Comparison code: 1517222874, WH 5B1/57070JUN,
External gear pump High Performance AZPB
