Przekaźnik miniaturowy elektromagnetyczny 24VDC D2N24-2880
Category: Miniature relays
CODE: D2N24-2880
CODE: D2N24-2880
Availability: Currently not available
Notify me about availability
Check deliveries
Product features
- Producent: TE Connectivity
- Type of relay: elektromagnetyczny
- Contact configuration: DPDT
- Tension: 24 VDC
- Rated coil voltage: 24V DC
- Contact current max.: 3A
- AC contacts rating @R: 0,5A / 125V AC
- DC contacts rating @R: 1A / 30V DC
- Manufacturer series: D2N
- Switched voltage: max. 220V DC, max. 250V AC
- Relay variant: miniaturowy
- Mounting: PCB
- Coil resistance: 2,88kΩ
- Coil voltage min.: 16,8V DC
- Coil voltage max.: 54,1V DC
- Operate time: 10ms
- Body dimensions: 20,3x10,1x11,43mm
- Release time: 10ms
- Coil power consumption: 200mW
- Mechanical durability: 150000000 cykli
- Contact resistance: 100mΩ
- Terminal pitch: 5mm
- Working temperature: -25...70°C
- Comparison code: 9-1393792-9
