Miniature electromagnetic relay 24VDC 41.31.9.024.0010 Palfinger EE102
Category: Miniature relays
CODE: 41.31.9.024.0010
CODE: 41.31.9.024.0010
Availability: Available (quantity: 6)
Check deliveries
Product description
Miniature electromagnetic relay
Product features
- Producent: FINDER
- Type of relay: elektromagnetyczny
- Contact configuration: SPDT
- Tension: 24 VDC
- Rated coil voltage: 24V DC
- Contact current max.: 25A
- AC contacts rating @R: 12A / 250V AC
- DC contacts rating @R: 12A / 30V DC
- Manufacturer series: 41.31
- Switched voltage: max. 220V DC, max. 400V AC
- Relay variant: miniaturowy
- Mounting: PCB
- Coil resistance: 1,44kΩ
- Coil voltage min.: 16,8V DC
- Coil voltage max.: 36V DC
- Body dimensions: 29x12,5x15,7mm
- Coil power consumption: 400mW
- Mechanical durability: 3000000 cykli
- Contact material: AgNi
- Terminal pitch: 3,5mm
- Working temperature: -40...85°C
