AZPFF-10-014/011LCX2020MX-S0463
Category: Rexroth
CODE: 0510555306
CODE: 0510555306
Availability: Available (quantity: 1) , shipping within 30 dni
Check deliveries
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Customer Part Number: 510555306
- Pump type: Toothed
- Working volume: 14 cm³/rev + 11 cm³/rev
- Drive shaft: Conical 1:5
- Turning direction: Direction of rotation left
- connection: Square flange DIN 3901/3902, Square flange DIN 3901/3902
- Front cover: Special execution
- Action: Pompa
- Gross weight: 5.6 kg
- Enclosure material: Aluminium
- Max. flow PU2: 45.1 l/min
- Max. intermittent pressure of pumping unit 1: 175 bar
- Roller type: Conical 1:5
- Max. intermittent pressure of pumping unit 2: 120 bar
- Maximum RPM: 4100 rpm
- Construction variant: Design variant F (4 ... 28 cm³/rev)
- Pump design variant 2: Design variant F (4 ... 28 cm³/rev)
- Net weight: 5.6 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 14 cm³/rev
- Custom version: Deviations from the standard catalog version, see drawing
- Cable connection: Square collar
- Pump 2 cable connection: Square collar
- Product: External gear assembly
- Comparison code: 3226942R93, R918C00956, 0510555306, 0510555303, AZPFF-10-014/011LCX2020MX-S0463
- End cover: Special execution
- Seal material: NBR
- Number: Shaft Ø 18 mm
- Pump size 2: 11
- Version: Al DG
- Libra: 5.6 kg
