Silnik hydrauliczny orbitalny WMR 250 cm3/obr (110 bar / max.160 bar) Waryński
Category: Orbital engines
CODE: WMR-250
CODE: WMR-250
Availability: Currently not available
Notify me about availability
Check deliveries
Product description
Orbital hydraulic motor WMR 250 cm³/rev (110 bar / max.140 bar / max.momentary 160 bar) Waryński. WMR series motors have a lightweight compact design, high torque. Possibility of parallel or series connection. In order to achieve longer service life, it is recommended that the optimum operating conditions are at the level of 1/3 to 2/3 of the maximum parameters.
Product features
- Producent: WARYNSKI
- Roller diameter: Ø25 mm
- Max. working pressure: 14 MPa (160 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 1/2" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 11 MPa (110 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 235 rpm
- Max. Nominal torque: 380 Nm
- Max Torque: 470 Nm
- Max. Working Fluid Flow: 60 l/min
- Max. output power: 6kW
