Silnik hydrauliczny orbitalny wzmacniany WMR-S 80 cm3/obr (175 bar / max.220 bar) Waryński
Category: Orbital engines
CODE: WMR-S-80
CODE: WMR-S-80
Availability: Available (quantity: 8)
Check deliveries
Product description
Orbital hydraulic motor reinforced WMR-S 80 cm³/rev (175 bar / 200 bar / max. momentary 220 bar) Waryński. WMR-S series motors have a lightweight compact design, high torque. Possibility of connecting in parallel or series. In order to achieve a longer service life, it is recommended that the optimum operating conditions are at the level of 1/3 to 2/3 of the maximum parameters. WMR-S Series motors have a reinforced design - thanks to which the operating parameters have been increased: pressure, torque and power in relation to WMR series motors.
Product features
- Producent: WARYNSKI
- Roller diameter: Ø25 mm
- Max. working pressure: 20 MPa (200 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 1/2" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 17.5 MPa (175 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 745 rpm
- Max. Nominal torque: 189 Nm
- Max Torque: 216 Nm
- Max. Working Fluid Flow: 60 l/min
- Max. output power: 12kW
