Silnik hydrauliczny orbitalny WMS 315 cm3/obr (125 bar / max.200 bar) Waryński
Category: Orbital engines
CODE: WMS-315
CODE: WMS-315
Availability: Available (quantity: 1)
Check deliveries
Product description
Orbital hydraulic motor WMS 315 cm³/rev (125 bar / max.160 bar / max.momentary 200 bar) Waryński. WMS series motors are characterized by a compact design, high torque, high absorption. Disk distribution ensures high efficiency, efficiency, smooth operation and long service life. Reinforced shaft seal allows both series and parallel connections of motors. In order to achieve a longer service life, it is recommended that the optimum operating conditions are at the level of 1/3 to 2/3 of the maximum parameters.
Product features
- Producent: WARYNSKI
- Roller diameter: Ø32 mm
- Max. working pressure: 16 MPa (160 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 1/2" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 12.5 MPa (125 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 230 rpm
- Max. Nominal torque: 551 Nm
- Max Torque: 625 Nm
- Max. Working Fluid Flow: 75 l/min
- Max. output power: 10kW
