Silnik hydrauliczny orbitalny WMT 160 cm3/obr (200 bar / max.280 bar) Waryński
Category: Orbital engines
CODE: WMT-160
CODE: WMT-160
Availability: Available (quantity: 3)
Check deliveries
Product description
Orbital hydraulic motor WMT 160 cm³/rev (200 bar / max.240 bar / max.momentary 280 bar) Waryński. WMT series motors are characterized by compact design, high torque, high absorption. They work in the range of significant torques at rather low rotational speeds. Possibility of parallel or series connection. Disc distribution ensures high efficiency, efficiency, smooth operation and long service life. In order to achieve longer service life, it is recommended that the optimal working conditions are at the level of 1/3 to 2/3 of the maximum parameters.
Product features
- Producent: WARYNSKI
- Roller diameter: Ø40 mm
- Max. working pressure: 24 MPa (240 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 3/4" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 20 MPa (200 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 625 rpm
- Max. Nominal torque: 450 Nm
- Max Torque: 559 Nm
- Max. Working Fluid Flow: 100 l/min
- Max. output power: 20.1kW
