Silnik hydrauliczny orbitalny WMT 400 cm3/obr (180 bar / max.240 bar) Waryński
Category: Orbital engines
CODE: WMT-400
CODE: WMT-400
Availability: Available (quantity: 11) , shipping within 2 dni
Check deliveries
Product description
Orbital hydraulic motor WMT 400 cm³/rev (180 bar / max.210 bar / max.momentary 240 bar) Waryński. WMT series motors are characterized by compact design, high torque, high absorption. They work in the range of significant torques at rather low rotational speeds. Possibility of parallel or series connection. Disc distribution ensures high efficiency, efficiency, smooth operation and long service life. In order to achieve longer service life, it is recommended that the optimal working conditions are at the level of 1/3 to 2/3 of the maximum parameters.Product features
- Producent: WARYNSKI
- Roller diameter: Ø40 mm
- Max. working pressure: 21 MPa (210 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 3/4" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 18 MPa (180 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 245 rpm
- Max. Nominal torque: 1008 Nm
- Max Torque: 1255 Nm
- Max. Working Fluid Flow: 100 l/min
- Max. output power: 22kW
