Silnik hydrauliczny orbitalny WMV 400 cm3/obr (200 bar / max.280 bar) Waryński
Category: Orbital engines
CODE: WMV-400
CODE: WMV-400
Availability: Available (quantity: 9)
Check deliveries
Product description
Orbital hydraulic motor WMV 400 cm³/rev (200 bar / max.240 bar / max.momentary 280 bar) Waryński. WMV series motors have a compact design, high torque and high absorption. Possibility of parallel or series connection. In order to achieve longer service life, it is recommended that the optimum operating conditions are at the level of 1/3 to 2/3 of the maximum parameters. WMV series motors are characterized by smooth operation, efficiency, transfer of high longitudinal and transverse loads.
Product features
- Producent: WARYNSKI
- Roller diameter: Ø50 mm
- Max. working pressure: 24 MPa (240 bar) - Note: maximum 6 seconds / 1 minute of engine operation (exceeding these parameters may damage the engine) MPa (bar)
- Connection threads: 1" BSP" inch
- Drain connection thread: 1/4" BSP" inch
- Max.Nominal pressure: 20 MPa (200 bar) - Note: maximum continuous engine operating pressure MPa (bar)
- Max. Rated speed: 375 rpm
- Max. Nominal torque: 1108 Nm
- Max Torque: 1440 Nm
- Max. Working Fluid Flow: 150 l/min
- Max. output power: 32kW
