Relay HF115F/024-2ZS4B
Category: Miniature relays
CODE: HF115F/024-2ZS4B
CODE: HF115F/024-2ZS4B
Availability: Available (quantity: 3114)
Check deliveries
Product features
- Producent: HONGFA RELAY
- Type of relay: electromagnetic
- Contact configuration: DPDT
- Switched voltage: max. 300V DC
- Switched voltage: max. 440V AC
- Relay variant: miniature
- Mounting: PCB
- Working temperature: -40...85°C
- Body dimensions: 29x12.7x15.7mm
- Operate time: 15ms
- Release time: 8ms
- Relay series: HF115F
- Terminal pitch: 5mm
- Contact resistance: 100mΩ
- Coil resistance: 1.44kΩ
- Coil voltage min.: 16.8V DC
- Contact material: AgNi
- Contact current max.: 8A
- DC contacts rating @R: 8A / 24V DC
- Coil power consumption: 400mW
- AC contacts rating @R: 8A / 250V AC
- Coil voltage max.: 36V DC
- Rated coil voltage: 24V DC
