AZPFF-12-005/004LCP2020KB-S0007
Category: Rexroth
CODE: 0510365305
CODE: 0510365305
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Turning direction: Direction of rotation left
- Seria pompy: AZPF
- Drive shaft: Conical 1:5
- Front cover: 2-hole mounting, diameter 50 mm (KHD)
- Action: Pompa
- Gross weight: 4.8 kg
- Enclosure material: Aluminium
- Max. flow PU2: 160 l/min
- Max. intermittent pressure of pumping unit 1: 280 bar
- Max. intermittent pressure of pumping unit 2: 280 bar
- Maximum RPM: 4000 rpm
- Construction variant: Design variant F (4 ... 28 cm³/rev)
- Pump design variant 2: Design variant F (4 ... 28 cm³/rev)
- Net weight: 4.8 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 55 cm³/rev
- Custom version: Deviations from the standard catalog version, see drawing
- Cable connection: Square collar
- Pump 2 cable connection: Square collar
- Product: External gear assembly
- End cover: Standard
- Comparison code: 0003 619 301, 0510 365 305
- Seal material: NBR, WDR w FKM
- Number: Shaft Ø 18 mm
- Pump size 2: 40 cm³/rev
- Version: zabezpieczenie przed korozją,
- Libra: 4.8 kg
0510365305_20230221.stp
