Bosch Rexroth gear pump AZPFF-11-011/005RCB2020MB
Category: Rexroth
CODE: 0510900046
CODE: 0510900046
Availability: Currently not available
Notify me about availability
Price available on request +48 42 712 66 07
Ask about the product
Product description
The primary function of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow rate and pressure). To reduce losses (leakage and heat), Rexroth external gear pumps are designed for high efficiency. This high efficiency is achieved through backlash compensation and high-precision manufacturing technology.
Product features
- Producent: Rexroth
- Turning direction: Right turns
- Seria pompy: AZPF
- Drive shaft: Conical 1:5
- Front cover: Rectangular flange diameter 80 mm
- Action: Pompa
- Gross weight: 5.2 kg
- Enclosure material: Aluminium
- Max. flow PU2: 17.5 l/min
- Max. intermittent pressure of pumping unit 1: 280 bar
- Max. intermittent pressure of pumping unit 2: 280 bar
- Maximum RPM: 3500 rpm
- Construction variant: Design variant F (4 ... 28 cm³/rev)
- Pump design variant 2: Design variant F (4 ... 28 cm³/rev)
- Net weight: 5.2 kg
- Noise level: Standardowy poziom hałasu
- Nominal size: 11 cm³/rev
- Cable connection: Square flange DIN 3901/3902
- Pump 2 cable connection: Square flange DIN 3901/3902
- Product: External gear assembly
- End cover: Flow rate regulating valve, residual flow rate internal
- Seal material: NBR
- Comparison code: PZS-686-458-421, 0 510 900 046
- Number: Bearing diameter Ø 18mm
- Pump size 2: 5 cm³/rev
- Version: fosforanowany, kołkowany
- Libra: 5.2 kg
0510900046_20230221.stp
